- Technical specifications

Reaction output measurement accuracy 1.0, IEC1036-1996

Rated voltage                     AC 220V

Reference current                  20A (MAX 80A)

Initial current                     20mA

Frequency                        50-60Hz

Impulse constant                   800imp/kwh

Measurement range                000000.00~999 999.99kWh

Built-in clock error                 0.5 sec/day

Electric power rate and time partition   3 rates at the maximum (minimum, medium, maximum), 8 time partition

Power consumption                0.5W max.

Rated current                     120V-250V

Maximum current for external control    warning: AC 250V, 1A/DC 30V 1A

Maximum single wire current         AC 250V, 1A/DC 30V 1A

Image-dividing output              5-24V DC

RS485 co㎜unication

Ultra-red rays co㎜unication

IC card co㎜unication (CPU)

PLC co㎜unication

Size                           274×165×89㎜

Weight About 2 150g

Ambient temperature              -25℃~+50℃

Relative humidity                Under 75%
